How to Choose the Right Slide?
Aolisheng has 27MM, 35MM, 45MM, 47MM, 51MM, 53MM, 71MM, and 76MM 8 different width slide rails. They have different usage scenarios and functions, which can be called heavy industrial slide rails, starting from 47MM width, heavy industrial slide rails The advantage of slide rails is that they have enough load-bearing and length, the maximum load-bearing can reach 500 pounds, and the longest can reach 80 inches. They are suitable for large drawers and equipment and other scenarios;
When you have a large drawer, how do you choose slides?
Step 1: You need to determine the size of your drawer to ensure that the size of your drawer will be larger than the size of the slide rail you choose; for example, if the size of the drawer is 84cm, then you must choose the size of 80cm or shorter; then ensure that your cabinet and drawer size There is enough space for installation on both sides; the reserved value is the thickness of the rail; this way you can confirm the size of the rail you need
Step 2: You need to estimate your drawer's weight. If it is less than 45KG, you can choose a drawer slide with a width of 45MM; if it is less than 68KG, you can choose a drawer slide with a width of 51MM; if it is less than 120KG, you can choose a drawer with a width of 47MM or 53MM. The heavy-duty slide rails; those less than 150KG can choose to use the industrial slides with a width of 71MM, and those less than 220KG can choose to use the heavy-duty industrial slides with a width of 76MM;
Step 3: You need to confirm your installation method, whether to install it on the drawer's side or the bottom. If it is more suitable to install the bottom, and the required weight is less than 120KG, you can directly choose a heavy-duty slide rail with a width of 47MM; if it exceeds 120KG And if you need bottom loading, you need to contact our sales to customize a suitable solution for you. If side mounting is possible, you can combine the information in the first and second steps to determine the most suitable drawer slide.
