The Aolisheng heavyduty locking drawer slides rail D2053 is designed for robust and secure drawer applications. To ensure a smooth and successful installation, it is essential to carefully follow the provided installation manual. This guide outlines the stepbystep process to install the drawer slides correctly.
Installation Preparation
Before beginning the installation, make sure to prepare all the necessary tools and components. Familiarize yourself with the contents of the package and read the installation instructions thoroughly.
Tools and Components
Ensure you have the following items ready for installation:
Aolisheng heavy duty locking drawer slides D2053
Use 12 M5 flat head screws for the installation.
Drill Used to create holes in the furniture or drawer to attach the slides.
Screws Used to attach the slides to the furniture and drawer.
Screwdriver Used to turn screws to tighten or loosen them.
Tape measure Measure the depth, width and height of your drawer to choose the slides that match your drawer
Wooden plugs Used to cover up any visible holes that were made during the installation process.
Ensure that you have the correct tools and materials so that you can install the locking drawer slides conveniently.
Slide Width Size:
The outer rail width is 53mm, the middle rail is 40mm, and the inner rail is 26mm.
The length of the slides is14" (350mm) apply to for a drawer depth of 14-16 inches.
Material Thickness and Rail Dimensions:
The material thickness is 20mm, the slider thickness is 19mm, and the rail width is 53mm.
Unlocking and Removing the Rail:
Press the lock handle to unlock the rail.
Pull the inner rail out (outer and middle rails are inseparable).
Press the lock handle and pull outward to remove the rail.
After the rails are separated, proceed to the next step of the locking drawer slides installation guide.
Removing Existing Slides (If Applicable)
If you are replacing old drawer slides, carefully remove them following these steps:
Unlock the existing locking drawer slides, if present, and remove any retaining clips or screws securing the slides.
Press the lock handle to unlock and release the drawer slides.
Pull the slides outward to remove them from the drawer and cabinet.
Installing the HeavyDuty locking drawer slides
Follow these steps to install the Aolisheng heavyduty locking drawer slides rail D2053:
Attaching the Cabinet Side Slides
- Position one cabinet side slide against the inside wall of the cabinet. Ensure it aligns with the marked installation points.
- Use a level to confirm that the slide is both horizontal and vertical.
- Mark the screw hole locations on the cabinet wall with a pencil or marker for accurate placement.
Securing the Cabinet Side Slides
- Remove the slide from the cabinet wall.
- Drill pilot holes at the marked screw hole locations to prevent any damage to the cabinet material.
- Align the locking drawer slides screw holes with the pilot holes and secure the slide to the cabinet wall using the provided screws.
Testing and Adjustments
Once the slides are installed, test their functionality by sliding the drawer in and out multiple times. Ensure smooth operation and make any necessary adjustments to achieve proper alignment and functionality.
Finalizing the Installation
After testing and adjusting, reattach the drawer securely to the cabinet using the lock handles, if applicable. Confirm that all screws are tightened, and the heavyduty locking drawer slides are fully operational.
Conclusion:
By following this installation manual carefully, you can install the Aolisheng heavyduty locking drawer slides rail D2053 with ease and ensure reliable and durable performance for your drawers. Always prioritize safety and precision during the installation process to maximize the functionality of your drawer slides.
Frequently Asked Questions
How do I release the lock on the Aolisheng heavyduty locking drawer slides rail D2053?
To release the lock on the drawer slides, simply press the lock handle and pull it outward. This will disengage the lock mechanism and allow you to open the drawer.
Can I use the Aolisheng heavyduty locking drawer slides rail D2053 for heavy drawers?
Yes, the Aolisheng heavyduty locking drawer slides rail D2053 is designed to handle heavy loads. It has a high load capacity and is suitable for heavyduty applications.
Can I install the Aolisheng heavyduty locking drawer slides rail D2053 on my existing drawers?
Yes, you can install the Aolisheng heavyduty locking drawer slides rail D2053 on existing drawers. However, you may need to remove the existing slides before installing the new ones.
Are the Aolisheng heavyduty locking drawer slides rail D2053 compatible with all types of cabinets?
The Aolisheng heavyduty locking drawer slides rail D2053 is designed to be compatible with most standard cabinet sizes. However, it is essential to check the dimensions and weight capacity of the slides to ensure they fit your specific cabinet.
